Power coverage range: 180kW~200kW
Applicable ship types:Marine generator sets
Technical Parameters
| Name | Main technical parameters | |||||
| Unit Model | CCFJ180J-W1 | CCFJ200J-W2 | ||||
| Power Type | Three-phase AC | |||||
| Rated power kW | 180 | 200 | ||||
| Rated voltage V | 400 | 400 | ||||
| Rated current A | 324.8 | 360.8 | ||||
| Rated frequency Hz | 50 | |||||
| Rated power factor COSφ | 0.8 (hysteresis) | |||||
| Rated speed r/min | 1500 | |||||
| Steady-state voltage regulation absolute value % | ≤2.5 | |||||
| Absolute value of transient voltage change rate % | Sudden discharge 60% rated current | ≤20 | ||||
| Sudden increase of 60% rated current | ≤15 | |||||
| Voltage stabilization time s | ≤1.5 | |||||
| Absolute value of voltage fluctuation rate % | ≤1 | |||||
| Absolute value of transient speed regulation % | Sudden increase 0-50% | ≤10 | ||||
| Sudden increase of 50-100% | ||||||
| Sudden unloading 100%-0 | ||||||
| Transient speed regulation stabilization time s | ≤5 | |||||
| Steady state speed regulation % | ≤5 | |||||
| Speed fluctuation absolute value % | ≤0.5 | |||||
| Insensitivity of unit speed control system % | ≤0.5 | |||||
| Rated fuel consumption g/(kW·h) |
≤230 | |||||
| Oil consumption rate g/(kW·h) | ≤0.35 | |||||
| Fuel brand | Summer: GB 19147-2016 superior or first-grade 0, 10 light diesel; | |||||
| Winter: GB 19147-2016 superior or first-class light diesel No. 0, No. -10, No. -20, No. -35 (select according to the ambient temperature) | ||||||
| Engine oil brand | Summer: 40CF, 15W/40CF; | |||||
| Winter: 30CD, 10W/30CD or other diesel engine oil suitable for the environment and not lower than CF grade in GB 11122-2006 | ||||||
| Startup method | Electric start | |||||
| Cooling method | Internal circulation: closed cycle water cooling, external circulation: open cycle water cooling | |||||
| Motor winding connection method | Three-phase four-wire | |||||
| Unit working mode | continuous | |||||
| Working environment conditions | Ambient temperature | 45°C | ||||
| Outboard water temperature | 32°C | |||||
| Tilt Angle | Heel 15°, Roll 22.5°, Pitch 7.5°, Pitch 10° | |||||
| Temperature rise | Thermal Class A | 55°C | ||||
| Measurement method R | ||||||
| Short Circuit | The AC generator and its excitation system can maintain at least 3 times the rated current for at least 2s under steady short-circuit conditions. | |||||
| Overload | 50% overcurrent 2min | |||||
| Diesel engine model | YC6MK300L-C25 | YC6MK330L-C22 | ||||
| Diesel engine rated power kW | 219 | 240 | ||||
| Generator Model | SB-HW4.D-180 (SAE1-14) |
SB-HW4.D-200 (SAE1-14) |
||||
| Generator rated power kW | 180 | 200 | ||||
| Unit mass kg | 1868 | 1933 | ||||
| Overall dimensions (length x width x height) mm | 2453×1063×1385 | 2432×1063×1385 | ||||
| Note: Dimensions and weight may vary depending on configuration. | ||||||
