Applicable ship types:Suitable for high-speed boats, law enforcement boats, official ships, yachts, tourist boats, etc.
Applicable ship types:This product is widely used in various ship engineering equipment such as transport ships, fishing boats, etc.
| Model | YC6MJ450L-C20 | YC6MJ410L-C20 | YC6MJ365L-C20 |
| Type | Vertical, in-line, water-cooled, four-stroke | ||
| Intake way | Turbo-charged& inter-cooled | ||
| No. of cylinders – Bore × Stroke（mm） | 6-131×145 | ||
| Displacement(L) | 11.73 | ||
| Compression ratio | 16.8：1 | ||
| Continuous power/speed（kW（Ps）/r/min） | 330 -450 /2100 |
300 -410 /1800 |
267 -365 /1500 |
| One-hour power/speed （kW（Ps）/r/min） | 363 -495 /2168 |
330 -450 /1858 |
293.7 -400 /1548 |
| Min.specific fuel consumption（g/kW•h） | ≤192 | ||
| Specific oil consumption（g/kW•h） | ≤0.5 | ||
| Engine oil capacity(L) | 28 | ||
| Min.steady working speed（r/min） | ≤945 | ≤810 | ≤675 |
| Crankshaft rotation direction (see from power output end) | Anticlockwise | ||
| Starting way | Electrical | ||
| Net weight（kg） | 1250 | ||
| Overall dimensions (LxWxH)(mm) | 1834×1028×1278 | ||
| Matched reduction gearbox or Adapted for marine gen-set | 300、J300、D300，etc | ||
| Certificate | ZC、CCS、EIAPP、国I | ||
| model | YC6MJ365L-C23 | YC6MJ410L-C23 | YC6MJ450L-C23 |
| Number of cylinders-bore x stroke (mm) | 6×131×145 | ||
| DisplacementL | 11.73 | ||
| Number of valves per cylinder | 4 | ||
| Air intake method | Supercharged intercooler | ||
| Rated power/speed (kW (Ps)/r/min) | 267 (365)/1500 | 300 (410)/1800 | 330 (450)/2100 |
| Overload power/speed (kW (Ps)/r/min) | 293.7 (400)/1548 | 330 (450)/1858 | 363 (495)/2168 |
| External characteristics Minimum fuel consumption g/kW.h | ≤188 | ||
| Certificate | ZC, CCS, EIAPP, National Second | ||
| Overall dimensions (length x width x height) (mm) | 1834×1028×1278 | ||
| Net weight (kg) | 1200 | ||
| Serial number | project | YC6MJ series marine emergency auxiliary generator |
| 1 | model | YC6MJ410L-C21 |
| 2 | Number of cylinders-bore x stroke (mm) | 6×131×145 |
| 3 | DisplacementL | 11.73 |
| 4 | Number of valves per cylinder | 4 |
| 5 | Air intake method | Supercharged intercooler |
| 6 | Rated power/speed (kW/r/min) | 300/1500 |
| 7 | Overload power/speed (kW/r/min) | 330/1500 |
| 8 | Certificate | CCS |
| 9 | Overall dimensions (length x width x height) (mm) | 2063×1125×1488 (with water tank) |
| 10 | Net weight (kg) | 1375 |
